1 - Circular Mode of Failure Page 3 of 6

Left Coordinate: (-200, 1,800) ft
Right Coordinate: (612, 1,969) ft

Seismic Coefficients
Horz Seismic Coef.: 0.15
Vert Seismic Coef.: 0

Anisotropic Strength Functions

150pcf-11° bedding 0-6°
Model: Spline Data Point Function
Function: Modifier Factor vs. Inclination
Curve Fit to Data: 100 %
Segment Curvature: 0 %
Y-Intercept: 0.667
Data Points: Inclination (°), Modifier Factor
Data Point: (-90, 1)
Data Point: (-0.9, 1)
Data Point: (0, 0.667)
Data Point: (6, 0.667)
Data Point: (6.1, 1)

TQs 150-17° bedding 0-6°
Model: Spline Data Point Function
Function: Modifier Factor vs. Inclination
Curve Fit to Data: 100 %
Segment Curvature: 0 %
Y-Intercept: 0.425
Data Points: Inclination (°), Modifier Factor
Data Point: (-90, 1)
Data Point: (-0.9, 1)
Data Point: (0, 0.425)
Data Point: (6, 0.425)
Data Point: (6.1, 1)

150pcf-17° bedding 0-6°
Model: Spline Data Point Function
Function: Modifier Factor vs. Inclination
Curve Fit to Data: 100 %
Segment Curvature: 0 %
Y-Intercept: 0.667
Data Points: Inclination (°), Modifier Factor
Data Point: (-90, 1)
Data Point: (-0.9, 1)
Data Point: (0, 0.667)
Data Point: (6, 0.667)
Data Point: (6.1, 1)
